Roller Chair – Fig. 275

For more product information please call (631) 665-9300
Diagram Notes

There are currently no diagram notes for this product.

Material

Carbon steel chair and axle with cast iron roller. Carbon steel chain and Axle also available in stainless steel.

Finish

Plain, electro-galvanized or painted.

Service

Designed for the support of pipe where longitudinal movement may occur due to expansion and contraction, and vertical adjustment is not necessary. May be bolted or welded to supporting member.

Approvals

There are no approval options for this product.

Ordering

Specify roller size, figure number and finish. Please remember to consider insulation thickness when sizing rollers.

Notes

Also available in 304 stainless steel (275SS). Available in domestic.

  • Hanger Size
    2
    2 1/2
    3
    3 1/2
    4
    5
    6
    7
    8
    10
    12
    14
    16
    18
    20
    24
  • Material Size
    4ga x 1.25
    4ga x 1.25
    4ga x 1.25
    3/8 x 1.50
    3/8 x 1.50
    3/8 x 1.50
    3/8 x 2.00
    3/8 x 2.00
    3/8 x 2.00
    1/2 x 2.00
    1/2 x 2.00
    1/2 x 2.50
    1/2 x 3.00
    1/2 x 3.00
    1/2 x 3.00
    5/8 x 4
  • Axle Size
    3/8
    1/2
    1/2
    1/2
    1/2
    5/8
    3/4
    3/4
    7/8
    7/8
    7/8
    1 1/8
    1 1/4
    1 1/4
    1 1/4
    1 1/2
  • B
    1 9/16
    1 7/8
    2 1/8
    2 1/2
    2 13/16
    3 3/8
    3 15/16
    4 1/2
    5 1/8
    6 3/8
    7 1/2
    8 3/8
    9 3/8
    10 7/16
    11 5/8
    14
  • C
    1 3/8
    1 5/8
    1 3/4
    2
    2 5/16
    2 1/2
    2 3/4
    2 13/16
    3
    3 5/8
    4 1/8
    4 11/16
    5 3/8
    6
    6 1/2
    7 7/8
  • D
    1 1/4
    1 1/4
    2
    2 1/2
    2
    3
    3 1/8
    3 3/8
    3 3/8
    5
    6
    6 1/2
    8 1/4
    9 1/4
    10 1/4
    12 1/4
  • E
    4 1/4
    4 7/8
    5 11/32
    6 11/32
    7 11/32
    8 1/4
    9 1/2
    10
    12 1/4
    14 1/2
    16 1/4
    18
    21
    22 7/8
    25 1/4
    30
  • F
    3/8
    3/8
    3/8
    3/8
    1/2
    1/2
    1/2
    1/2
    5/8
    5/8
    5/8
    3/4
    3/4
    3/4
    3/4
    7/8
  • Wgt Each (lbs)
    0.94
    1.18
    1.32
    2.58
    2.94
    3.64
    5.72
    6.98
    8.16
    11.96
    15.86
    21.58
    34.50
    36.50
    45.00
    77.50
  • Max REC Load (lbs)
    390
    390
    390
    390
    950
    950
    950
    1350
    1350
    1730
    2400
    3130
    3970
    4200
    4550
    6160
