Copper Two Hole Tubing Strap – Fig. 231CT

For more product information please call (631) 665-9300
Diagram Notes

There are currently no diagram notes for this product.

Material

Carbon steel.

Finish

Copper plated.

Service

Designed as a light duty support for copper tubing. Attaches directly to horizontal or vertical structural member.

Approvals

There are no approval options for this product.

Ordering

Specify tube size and figure number.

Notes

Available in domestic.

  • Pipe Size
    1/4
    3/8
    1/2
    3/4
    1
    1 1/4
    1 1/2
    2
  • Pipe OD
    0.375
    0.500
    0.625
    0.875
    1.125
    1.375
    1.625
    2.125
  • Material Size
    20ga x 1/2
    20ga x 1/2
    20ga x 1/2
    20ga x 1/2
    20ga x 1/2
    20ga x 1/2
    18ga x 3/4
    18ga x 3/4
  • Hole Size A
    3/16
    3/16
    3/16
    3/16
    3/16
    3/16
    7/32
    7/32
  • B
    1 3/4
    1 7/8
    2 1/8
    2 3/8
    2 7/8
    3 1/8
    3 5/8
    4 1/4
  • C
    1 1/8
    1 1/4
    1 1/2
    1 5/8
    2 1/4
    2 1/2
    2 3/4
    3 3/8
  • Wgt Each (lbs)
    0.01
    0.01
    0.01
    0.02
    0.02
    0.04
    0.05
    0.06
