Rooftop Supports
Base with 14 ga. (1.9mm) Galv. Channel – 1”(25.4mm) high – Fig. DBS
Dimensions: 5” (127mm) High x 6” (152mm) Wide x Length (overall length)
Ordering: Specify figure number and model number.
Base with 12 ga. (2.6mm) Galv. Channel – 2-7/16” (62mm) high – Fig. DB6S
Dimensions: 6-7/16” (163mm) High x 6” (152mm) Wide x Length (overall length)
Ordering: Specify figure number and model number.
2 Bases with 12 ga. (2.6mm) Galv Channel – 1-5/8” (41mm) high – Fig. DB10S
Dimensions: 5-5/8” (143mm) High x 6” (152mm) Wide x Length (bridge length)
Ordering: Specify figure number and model number.
2 Base Supports with 12 ga. (2.6mm) Galv Channel – 1-5/8” (41mm) high
– Fig. DBDSS
Dimensions: Height (overall) x Width (overall) x Length (overall)
Ordering: Specify figure number and model number.
Base with 14 ga. (1.mm) Galv Channel – 1” (25.4mm) high and Pipe Roller Assembly – Fig. DBRSF
Dimensions: Height to Bottom of Pipe x 6” (152mm) Wide x Long (length)
Ordering: Specify figure number and model number.
Base with two 1/2” (12.17mm) – 13” (330mm) Electro Zinc All Threaded Rod Risers and a B 3114 – 3-1/2” (88.9) Pipe Roll with Sockets – Fig. DBRSA
Dimensions: Overall Height as Specified Base – 4” High (101mm) x 6...
Ordering: Specify figure number and model number.
Base with two 1/2” (12.7mm) – 13 Electro Zinc All Threaded Rod Risers and 14 ga. (1.9mm) Galv. Slotted Channel – Fig. DBRES
Dimensions: Overall Height as Specified Base – 4” High (101mm) x 6...
Ordering: Specify figure number and model number.
Base with 3/8” – 16 Electro Zinc All Threaded Rod and Hinged Pipe Clamp – Fig. DBMS
Dimensions: Height to Pipe Center x 6” (152mm) Wide x 4.8” (12mm) Long (overall length)
Ordering: Specify figure number and model number.
Base with 3/8” – 16 Electro Zinc All Threaded Rod and Hinged Pipe Clamp (Base Only) – Fig. DBMSO
Dimensions: 4” (101mm) High x 6” (152mm) Wide x 9.6” (244mm) Long (base length)
Ordering: Specify figure number and model number.
